NEL-10FD Electric Heating Freeze Dryer

This NEL-10FD Electric Heating Freeze Dryer is widely used in medicine, pharmacy, biology research, chemical industry and food production ,etc.

Availability:
Quantity:

freeze dryer

Brief Introduction of the  NEL-10FD Electric Heating Freeze Dryer

 NEL-10FD Electric Heating Freeze Dryer is widely used in medicine, pharmacy, biology research, chemical industry and food production ,etc. After the freeze drying process,a long term preservation is much easier. They can be restored to the original state and maintain their chemical and biological characteristics after being watered.



Freezing and drying process of NEL-10FD (electric heating)  are finished in the same place (patented product). It changes the cumbersome operation of the drying process in the past, prevents the contamination of materials, and realized dry sublimation automatically. The model is equipped with shelf heating and has programmable functions. It can memorize freeze-dried curves and comes with u-disc extraction function for users to observe the lyophilization process of materials.



This NEL-10FD Standard Type Experimental Freeze Dryer is especially suitable for the freeze-drying of Cordyceps sinensis


freeze dryer

NEL-10FD Electric Heating Freeze Dryer Suitable for freeze drying of bulk (liquid, pasty, solid) conventional materials.


Model

NEL-10FD standard type

Freeze drying area

0.2㎡

Shelf dimensions

400×270mm

Tray dimensions

395×265mm

Tray numbers

2pcs

Shelf spacing

70mm

Shelf temp. range

-50℃~+70℃

Cold trap temp.

≤-60℃,optional ≤-80℃

Ice collecting capacity

≥6KG/24h

Pumping speed

4L/S

Ultimate vacuum

≤5pa

Power

2000w

Main unit weight

210kg

Main unit dimensions

655×640×1200mm

Cooling mode

wind cooled

Shipping weight

2L(thickness 10mm)
