Model | GDSZ-50/20 | GDSZ-50/40 | GDSZ-50/80 |
Volume | 50L | ||
Reservoir volume（L） | 11 | ||
Heating volume（L） | 2 | ||
Heating tank size(mm) | ￠90×300 | ||
Tank size(mm) | 300*300*120 | ||
Temperature range（℃） | -20/+200 | -40/+200 | -80/+200 |
Load minimum temperature | -22℃ | -42℃ |
-82℃ |
Heating power（W) | 6000 | ||
Cooling power（W) | 6160-1820 | 10280-2560 | 7740-180 |
Meter temperature range | -100℃-400℃ | ||
Temperature accuracy（℃） | ±0.1 | ||
Circulating pump power（w） | 280 | ||
Lift（m) | 10 | ||
Flow（L/min） | 35 | ||
Pressure（Mpa） | 4 | ||
Cold medium | R22 | ||
Out of the nozzle | 4＃(Low into high outlet) | ||
Temperature control mode | Microcomputer intelligent temperature control, LCD | ||
Machine size(mm) | 720*650*1120 | ||
Weight(KG) | 95 | 124 | 180 |
Remark | According to user requirements do explosion-proof, can be equipped with double inlet and outlet valves | ||
